Thrust & Payload Testing Rig
Motor and propeller thrust measurement rig for drone performance R&D. (Qty available: 1)
- Defence-grade, configured to your mission
- Commissioning & operator training included
- AMC, spares & field support available
Available to Defence / Govt
Price on request
Supplied to authorised defence & government users only.
Overview
About the Thrust & Payload Testing Rig
A precision thrust and payload testing rig for measuring motor KV, thrust, torque, power consumption and efficiency across different propeller and ESC combinations.
Specifications
Technical specifications
| Max Thrust Measurement | 50 kg |
|---|---|
| Force Resolution | 1 g |
| Torque Measurement | 5 N·m max |
| Current Measurement | 0–100 A |
| Interface | USB to PC with logging software |
| Compatible Motors | Up to 100 mm diameter |
Capabilities
Key features
- 50 kg max thrust measurement
- 1 g force resolution
- Live RPM, current, voltage logging
- PC software with CSV export
- Compatible with all motor sizes
Use cases
Applications
- Motor and propeller selection
- ESC calibration and profiling
- Efficiency and endurance research
- Propulsion system optimisation
